SMI-35, 1-COLOR MACHINE
Introducing the SMI-35 Pad Printer: A High-Speed, User-Friendly, and Affordable Printing Solution
Upgrade your pad printing department with the SMI-35, a high-speed and cost-effective addition to your printing arsenal. Designed for ease of use and versatility, this tabletop model offers a range of features suitable for various applications.
Key features:
- Modular System with Automation Capability: Seamlessly integrate into automated processes with a simple handshake tie-in
- Compact Design: The tabletop model boasts a small footprint, making it suitable for use in even the most confined spaces
- Versatility: Ideal for both promotional products and fully automated systems
- PLC Controlled: Ensures precise and efficient operation
- Economically Priced: Accessible to all market segments without compromising on performance
- Tool-Free Operation: No clamping or special tools required for setup
- Front or Back Plate Loading: Provides flexibility in loading configurations
- Upgradeable to Automation: Effortlessly transition to automated processes as your needs evolve
- Compatibility with Accessories: Enhance functionality with accessories such as automatic tape-off systems, two-color attachments, and rotary table indexing
Specifications:
- Maximum Printed Area: One 90mm ink cup, print area 3.125” DIA
- Electrical Requirements: 120 VAC 50-60 HZ (other voltage available upon request)
- Dimensions: 20” x 6” x 21” (LxWxH), weighing 60lbs
Experience the efficiency and adaptability of the SMI-35 Pad Printer, a reliable solution for businesses of all sizes. Upgrade your printing capabilities without compromising on quality or budget.
🇺🇸 Made In USA
SMI-250, 1-4 COLOR MACHINE
Introducing the SMI-250: A Powerful and Flexible Pad Printer Setting New Standards in the Industry
Key features:
- Versatile Cliché Compatibility: Accepts various cliché sizes for cost savings and increased flexibility
- 5” Vertical Pad Stroke: Allows for efficient and precise printing
- Pneumatic Drive: Ensures simple and reliable operation
- Closed Cup Design: Featuring a 3.5 DIA cup (standard) for optimal ink containment
- Powder Coated Cabinet: Facilitates easy cleanup and maintenance
- Automatic Cycle Mode: Adjustable cycle rate for enhanced efficiency
- Foot Switch: Enables single-cycle operation for enhanced control
- Ink Mix Cycle: Facilitates thorough mixing for consistent printing
- Setup Mode: Fast and efficient setup for increased productivity
- Independent Pad Strokes: Allows for independent control of plate and part movements
- High Cyclic Capability: Achieves a rate of 1800 cycles per hour (application dependent)
- Reinforced Construction: Frame reinforced for durability and longevity
- Quick Conversion: Easily converts from cup slide printer to front-to-back printer for added versatility
Specifications:
- Maximum Printed Area:
- One to two 90mm ink cups, print area 3.125” DIA
- One 130mm ink cup, print area 4.5” DIA
- One 180mm ink cup, print area 6.25 DIA
- Electrical Requirements: 120 VAC 50-60HZ (other voltages available upon request)
- Dimensions: 36” x 12” x 21” (LxWxH), weighing 90 lbs
The SMI-250 Pad Printer redefines printing standards with its robust design, unmatched flexibility, and advanced features. Elevate your printing capabilities with this powerhouse that promises efficiency, reliability, and adaptability.
🇺🇸 Made In USA
SMI-HD, 1-6 COLOR MACHINE
Introducing the SMI-HD – HD Series: Versatility Built Tough
Unleash unparalleled printing capabilities with the SMI-HD, hailed as the most versatile pad printer on the market. This powerhouse is designed to handle a diverse range of applications with incredible adaptability.
Key Highlights:
- Adjustable Cliché Stroke: Run clichés ranging from 225mm to 400mm effortlessly, offering adaptability for various print sizes
- Quick Transition: Switch from cliché printing to cup slide printing with a remarkable print capability of up to 110cm in just minutes
- Robust Construction: The HD pad printer is built to withstand the test of time, boasting a frame constructed support and pad pressure at 3000N
Key features:
- Six-Inch Vertical Pad Stroke: Ensures precision and versatility in printing
- Touch Screen Interface Panel: Streamlines operation with an intuitive user interface
- Color Options:
- Up to six colors with 90mm ink cups
- Up to five colors with 130mm ink cups
- Up to three colors with 180mm ink cups
- Extended Cup Slide: Accommodates printable lengths up to 110cm for larger applications
- Servo Head:
- Customization Options: Tailor the HD Series with numerous available options based on specific print requirements
- Limitless Possibilities: Explore a myriad of options; contact us for a detailed list and discuss your specific needs
Discover the unmatched versatility of the SMI-HD pad printer, a printing solution that adapts to your unique requirements. Elevate your printing experience with cutting-edge technology and robust construction that stands the test of time. For a comprehensive list of options and to discuss your specific needs, please call or email us today.
🇺🇸 Made In USA
SMI-360 SERVO, 1-2 COLOR MACHINE
Introducing the SMI-360 Servo Catheter Tube Printer, where Precision Meets Innovation
Key features:
- Intelligent Parameter Calculation: Effortlessly choose the French or diameter size, and let the printer calculate necessary parameters with precision
- Memory Recall: Save and recall specific tube sizes and locations from memory, streamlining your printing processes for enhanced efficiency
- Effortless Artwork Handling: Print multiple artworks per cliché without manual adjustment of the print pad or part-holding nest, ensuring seamless operation
- Ink Tack Dwell System: Achieve pristine results with a system that prevents smearing or smudging on the catheter fixture during printing
- Programmable Pad Cleaning: Enhance cleanliness and maintain quality by taping off before each print cycle with the programmable automatic pad cleaning feature
- All Electric: Experience seamless and efficient operation with an all-electric system that ensures reliability
- User-Friendly Interface: Navigate and control the printer effortlessly with the intuitive touch screen interface for user convenience
- Preprogrammed Sizes: Benefit from preprogrammed size options catering to various preferences, ensuring adaptability to different customer needs
- Custom Configurations: Tailor the printer to your specific requirements with customizable configurations and automation options available upon request
Specifications:
- Power: 120 VAC, 50-60HZ (other voltages available upon request)
- Ink Cup Size: Accommodates up to 130mm ink cups for versatile printing options
- Printing Capacity: Standard capacity of up to 80cm, with the flexibility to arrange custom sizes to meet specific project needs
Experience precision and innovation in every print with the SMI-360 Servo Catheter Tube Printer—a solution that adapts to your unique requirements, ensuring top-notch results in every project.
🇺🇸 Made In USA
